J236

Vise Accessories

For Use With Order No. Price

BT40 GM68MM40BT Price BT50 GM68MM50BT Price CAT40 GM68MM40V Price CAT50 GM68MM50V Price

1107

Toolholder Vises

Mounts horizontal or vertical Access both ends of toolholder Solid vise type grip Durable anodize finish Mounts to bench or toolcart Will not damage toolholder Handle ratchets for convenience

Spindle Taper Order No. Price

40 Taper GM68499540 Price 50 Taper GM68499550 Price

28830

Rotary Tool Clamps

6-Position 45 Mounting Fixture Multiple use on ISO, Caterpillar and BT shanks Easy access for combined assembly of cutting tool and pull stud in one position Hardened and ground internal taper Tool holder secured by safety clamp screw Compact design for easy mounting on work table or tool cart

Size Order No. Price

#30 R8 GK4555090 Price #40 5C GK4555110 Price

1692

SpinLMate Taper Socket Cleaning Tools

Quickest, surest, safest method available for cleaning spindle and adapter sockets, tool presetter sockets and tool storage pockets Cleans the entire length of the taper socket in 3 seconds or less insures a Solid, Concentric, Repeatable cutting tool to spindle connection Complete tool includes 1 'ST' Blade Set and 1 'VR' Blade Set

Spindle Taper Dimension B Dimension C Dimension A Flange Dimension L1 Dimension L2 Order No. Price

CAT/ BT40 3.500" 4.250" 5.0" 1" 5.500" 2.150" TS1029902 Price CAT/ BT50 5.250" 6.000" 6.0" 1" 7.500" 3.500" TS1029903 Price

1542

CNC Tightening Fixtures

Multiple usage on toolholder shank CAT, BT, NMTB & ISO Enables strong gripping power of cutting tools Access both ends of toolholders simultaneously Secures maximum protection of toolholder Tools can be mounted in vertical and horizontal positions High quality compact and rigid design for mounting on work table or tool cart

Black Size Order No. Price

#30 R8 GK4572340 Price #40 5C GK4572360 Price #50 GK4572460 Price

Red Size Order No. Price

#30 R8 GK4574340 Price #40 5C GK4574360 Price #50 GK4574460 Price

Yellow Size Order No. Price

#30 R8 GK4573340 Price #40 5C GK4573360 Price #50 GK4573460 Price

1691

Replacement Blades

Size Order No. Price

#30 R8 GK35230 Price #40 5C GK35240 Price #50 GK35250 Price HSK63 GK35H063 Price

1693

Spindle Cleaners

Plastic molded handle Cleaning strips resist oil and grease Cleans oil and grease build up in spindles Easy to use

Model No Spindle Taper Order No. Price

DSTSCH-030 BT30 GG3536000 Price DSTSCH-040 CAT40/BT40 GG3536001 Price DSTSCH-050 CAT50/BT50 GG3536002 Price DSTSCH-063 HSK63 GG3536003 Price DSTSCH-100 HSK100 GG3536004 Price F.O.B. East Bernard, TX

1076

Smart Tool-Setter Tightening Fixtures

Toolholder taper protected from chips & scratches Teflon Based Xylan coating Quick Lock & Setting Multi-position setting Heavy duty construction Precise quality & workmanship
